Agricultural Tyre ALT701 4.00-8 6.00-12 7.50-16 8.3-24

TIANFU brand Bias Agricultral(AGR) Tyre ALT701

PRODUCT FEATURES:

  • Superior traction performance
  • Adopt large block, deep pattern design, longer service life
  • Excellent wear resistance
  • Strong anti-slipping ability and anti-skid
  • Series: Agricultural Tire
  • BRAND:  TIANFU
  • Available size: 4.00-8 6.00-12 7.50-16 7.50-20 8.3-24

Tyre Spec

SIZE Ply Rating Speed Symbol RIM Sectiong Width(mm) Overall Diameter(mm) Max Load kg(Single/dual) AT COLD
Measuring Permitted kPa(S/D) kgf/cm(S/D)
4.00-8(11Pitch) 4 / 3.00D 2.50C 112 415 225 275 27.5
6.00-12(16 Pitch) 6 / 4.50E 5.00F 165 640 405 250 2.5
6.00-16(17 Pitch) 6 / 4.50E 5.00F 165 745 495 250 2.5
7.50-16(18/19/20 Pitch) 8 / 5.50F 5.00F,6LB 205 810 750 270 2.7
7.50-20(18Pitch) 8 / 5.50F 5.00F,6.00F 205 910 870 270 2.7
8.3-24(18Pitch) 6 / W7 W6 210 995 810 240 2.4
